WISY Storage Tank

  • Compression-resistant storage tanks
  • 4.5 m³ or 5.5 m³ storage volume
  • Manufactured without seams
  • Large access shaft
  • DN 100 tube bushings with seals
  • Non-slip cover, vehicle-duty capacity
Cistern for rainwater

Overview

WISY Storage Tank during production in Germany
WISY Storage Tank - Made in Germany.

Stable and leak-tight - guaranteed!

The WISY storage tank is optimally shaped to withstand vertical compressive loads. The rainwater storage tank is a seamless one-piece unit for long-term leak-tightness. We offer a 20-year guarantee on the durability of the environmentally friendly polyethylene tank material.

Thanks to their exceptional strength, WISY storage tanks are capable of withstanding the weight of passing road vehicles. This means that they can be installed under the driveway as well as in the garden. Even when weather conditions are wet, the non-slip cover is safe to walk over.

Easy to handle on site

Thanks to their light weight and two rugged lifting eyes, WISY storage tanks are particularly easy to handle on site (using a mini-digger, for example). When the excavated pit is filled up with gravel the storage tank is fully supported from below. Tube bushings with fitted seals make installation even easier. For additional safety, a compressed water equalizing valve is fitted in the tank base for protection in the event of groundwater collection around the tank. The wide access shaft ensures ease of entry for maintenance work.

Cistern with rainwater filter

Basic equipment includes:

  • Three DN 100 connection bores with seals
  • Two lifting eyes
  • Cover made of vehicle-duty plastic
  • Compressed water equalizing valve in tank base

Complete equipment LineAr includes:

(additionally compared with basic equipment)

  • LineAr 100 Rainwater filter
  • Inflow calming tube made of stainless steel
  • Piping

The tanks are delivered with all components and tubing assembled ready for installation.

Complete equipment WFF includes:

(additionally compared with basic equipment)

  • Vortex fine filter (WFF 100 with filter insert of WFF 150)
  • Multisiphon with vermin guard and backflow prevention device
  • Inflow calming tube made of stainless steel
  • Piping

The tanks are delivered with all components and tubing assembled ready for installation.

Cistern for rainwater, dimensional drawing

Technical Data

Sizes 4,5 m³ 5,5 m³
Diameter A 2.350 mm 2.350 mm
Tank height B 2.510 mm 2.770 mm
Service duct connection C 1.690 mm 1.950 mm
Drain connection D 1.285 mm 1.545 mm
Rainwater inlet E 1.895 mm 2.155 mm
Weights
Basic equipment 220 kg 250 kg
Complete equipment 250 kg 280 kg
